Standard Design Features
?Cryogenic Service to -196 C
?Forged or Cast Steel Body
?Floating & Trunnion Mounted Ball
?Extended Bonnet
?Lip Seal
?Cavity Pressure Relief
?Anti Blow-Out proof Stem
?Anti-Static Device
?Fire Safe Design
?In House Cryogenic Testing (On Request)

Production Range
?Valve size : 1/2″~24″ (DN15-DN600)
?Pressure : ASME Class150~1500 (PN20-PN250)
?Temperature : -196℃~ 200℃
?Body Materials :
Stainless Steel, Cryogenic Alloy Steel, Dual-Stainless steel
?Trim (Ball/Seat Ring/Stem) :
Stainless, Cryogenic resistant with nonmetal seal seat/ring

Design Standards
?Design : ASME 16.34/API 6D
MESC 77/200
BS 6364
?Face to Face : ASME B16.10
?BW End : ASME B16.25
?Test : API 598/BS 6755/API6D
?Fire Safe Test : API 607/API 6FA
?Special : NACE MR-01-75
